Elitech Intelligent HVAC Vacuum Pump 7 CFM 2 Stage Vacuum Gauge App Control, SVP-7
|
3
questions
In stock
Elitech SVP-7 refrigerant vacuum pump is a 7 CFM, dual-stage unit with an innovative touch screen design. The informative screen displays the pressure at the vacuum inlet and graphs the pressure ...
Elitech SVP-7 refrigerant vacuum pump is a 7 CFM, dual-stage unit with an innovative touch screen design. The informative screen displays the pressure at the vacuum inlet and graphs the pressure change over time to help you know more about how your HVAC job is going on. SVP-7 enables your smartphone App to connect with the pump in order to realize remote control, setting, real-time reading, and data report export function to make your work more convenient.
Features
- 4" Large Visual Touch Screen: The big screen enables you to know everything about the pump in one glance. By just a simple touch on the screen, you can set the parameter of the pump and control its working status.
- Detect System Leakage Level: Collect actual working vacuum value data and infer the leakage level of the system.
- Vacuum Graph: View the vacuum change process in real-time.
- Innovative Elitech Tools APP ( Supported ioS and Android): Real-time Monitoring on Elitech Tools, allows users to manage all Elitech tools such as vacuum pump, digital manifold, vacuum gauge, pressure gauge, refrigerant charging scale on one app, much more efficient and intelligent.
- Auto Control: Intelligent control of the motor, automatic Switch on and off, achieving unattended operation. Analyze the leakage status and job completion time.
User manual: Download
Certificate: CE
Video: Vacuum Pump Operation Instruction
30 Days Free Return
1 Year Warranty
Technical Parameter
| Model | SVP-7 |
| Stage | 2 Stages |
| Power Supply | 110V/60HZ |
| Motor | AC Induction Motor |
| Speed Regulation | Fixed Speed |
| Vacuum Accuracy |
±10% of Reading / ±10 microns(@1-10000 microns) ±20% of Reading(@10000-19000 microns) |
| Operating Temperature | 5°C~40°C (41°F~104°F) |
| Transmission Distance | 30ft / 10m |
| Limit Vacuum | 15 microns |
| Pumping Rate | 7 CFM (3 L/S) |
| Motor Power | 3/4 HP (550 W) |
| Fuel Volume | 22oz (650ml) |
| Overall Dimension | 18.5inx10.5inx14.8in (470mm*267mm*380mm) |
| Weight | 34.2lbs / 14.8kg |
| Air Inlet | 1/4 SAE |
Notes: Above 60,000 microns, vacuum value is not shown and the screen shows --. The waiting time for the vacuum reading is longer for a large system.
Built-in Vacuum Sensor VS Micron Gauge: Due to the different placements of vacuum sensors, the vacuum reading of the pump may vary with the micron gauge which is connected to the system. The airflow is not the same at different placements in the system when vacuuming. The air density is larger which is far away from the pump, so the readings of vacuum are high.
Oil Mist Notes:
When starting vacuuming, the pressure is relatively high, the air outlet is large. The vacuum pump has a large exhaust volume. So there will be oil mist overflowing with gas. This is a common feature of rotary vane vacuum pumps. Oil mist appears at first which is a normal phenomenon. When the vacuum drops to a very low value, the exhausting volume is small and there will be no oil mist. Therefore, the vacuum pump should regularly inspect the oil level to avoid running out of oil.
